YE4 IE4 High Efficiency Three Phase Asynchronous Motor

PREV: YBX3 YBX4 YBX5 Series High-Efficiency Flameproof Three-Phase Asynchronous Motors
NEXT:No next product

Product Advantages Product Features

The YE4 series of ultra-high-efficiency three-phase asynchronous motors is a new, upgraded, and highly efficient product independently developed by our company. Its efficiency complies with the Grade 2 energy efficiency standard specified in GB18613-2020 and meets the IE4 efficiency criteria outlined in IEC60034-30-1. The mounting dimensions adhere to both IEC and national standards, enabling customers to achieve rapid and seamless interchangeability. The YE4 series motors feature an Aesthetically pleasing design and are characterized by low loss, low noise, low vibration, safety, reliability, and ease of maintenance.

These products are primarily designed to serve as supporting components for equipment such as fans, water pumps, compressors, and construction machinery. They are widely utilized across various sectors, including ventilation and refrigeration, commercial and residential buildings, oil and gas, petrochemicals, coal and chemical processing, metallurgy, electric power and nuclear energy, marine engineering, and industrial automation.

Type No.	Rated output	Speed	Votage	IN	EFF	Power factor	Rated torque (Tn)	Locked torque	Lockod current Rated torque 1ST/TFL	Max torque Rated toroue TMTFL	Noise level LW dB(A)
YE4	(kW)	( r/min)	(V)	(A)	η(%)	(cosφ)	N.m	Rated torque TST/TFL
380V 50H25ynchronous spaed 3000r/min(2polas)
YE4-80M1-2	0.75	2875	380	1.62	83.5	0.83	2.5	2.3	7.0	2.3	62
YE4-80M2-2	1.1	2885	380	2.32	85.2	0.83	3.65	2.2	7.3	2.3	62
YE4-90S-2	1.5	2890	380	3.06	86.5	0.85	4.97	2.2	7.6	2.3	67
YE4-90L-2	2.2	2895	380	4.36	88.0	0.86	7.32	2.2	7.6	2.3	67
YE4-100L-2	3	2900	380	5.84	89.1	0.87	9.88	2.2	7.8	2.3	74
YE4-112M-2	4	2915	380	7.64	90.0	0.88	13.2	2.2	8.3	2.3	77
YE4-132S1-2	5.5	2925	380	10.3	90.9	0.88	18	2.0	8.3	2.3	79
YE4-132S2-2	7.5	2925	380	13.9	91.7	0.89	24.7	2.0	7.9	2.3	79
YE4-160M1-2	11	2940	380	20.2	92.6	0.89	35.7	2.0	8.1	2.3	81
YE4-160M2-2	15	2940	380	27.4	93.3	0.89	48.9	2.0	8.1	2.3	81
YE4-160L-2	18.5	2940	380	33.6	93.7	0.89	60.3	2.0	8.2	2.3	81
YE4-180M-2	22	2945	380	39.8	94.0	0.89	71.3	2.0	8.2	2.3	83

YE4-200L1-2	30	2970	380	54.2	94.5	0.89	96.5	2.0	7.6	2.3	84
YE4-200L2-2	37	2970	380	66.6	94.8	0.89	119	2.0	7.6	2.3	84
YE4-225M-2	45	2970	380	80.8	95.0	0.89	145	2.0	7.7	2.3	86
YE4-250M-2	55	2970	380	98.5	95.3	0.89	177	2.0	7.7	2.3	89

YE4-280S-2	75	2980	380	134	95.6	0.89	241	1.8	7.1	2.3	91
YE4-280M-2	90	2980	380	160	95.8	0.89	289	1.8	7.1	2.3	91
YE4-315S-2	110	2985	380	196	96.0	0.89	353	1.8	7.1	2.3	92
YE4-315M-2	132	2985	380	235	96.2	0.89	423	1.8	7.1	2.3	92
YE4-315L1-2	160	2985	380	284	96.3	0.89	513	1.8	7.2	2.2	92
YE4-315L2-2	185	2985	380	328	96.5	0.89	593	1.8	7.2	2.2	92
YE4-315L3-2	200	2985	380	355	96.5	0.89	641	1.8	7.2	2.2	92
YE4-355M-2	250	2990	380	433	96.5	0.91	801	1.6	7.2	2.2	100
YE4-355L-2	315	2990	380	545	96.5	0.91	1009	1.6	7.2	2.2	100
YE4-3551-2	355	2990	380	613	96.5	0.91	1138	0.9	7.2	1.8	104
YE4-3552-2	375	2990	380	655	96.5	0.90	1202	0.9	7.2	1.8	104

Type No.	Rated output		Speed		Votage		IN		EFF		Power factor		Rated torque (Tn)		Locked torque		Lockod current Rated torque 1ST/TFL		Max torque Rated toroue TMTFL	Noise level LW dB(A)
YE4	(kW)		( r/min)		(V)		(A)		η(%)		(cosφ)		N.m		Rated torque TST/TFL
380V 50Hz Synchronous Speed 1500r/min(4 poles)
YE4-80M1-4		0.55		1425		380		1.35		83.9		0.75		3.70		2.4		5.2	2.3	56
YE4-80M2-4		0.75		1425		380		1.80		85.7		0.75		5.03		2.3		6.6	2.3	56
YE4-90S-4		1.1		1430		380		2.55		87.5		0.75		7.35		2.3		6.8	2.3	59
YE4-90L-4		1.5		1430		380		3.31		88.2		0.78		10.1		2.3		7.0	2.3	59
YE4-100L1-4		2.2		1435		380		4.71		89.5		0.79		14.5		2.3		7.6	2.3	64
YE4-100L2-4		3		1440		380		6.31		90.4		0.80		20.2		2.3		7.6	2.3	64
YE4-112M-4		4		1450		380		8.35		91.1		0.80		26.3		2.2		7.8	2.3	65
YE4-132S-4		5.5		1460		380		11.3		91.9		0.80		36.0		2.0		7.9	2.3	71
YE4-132M-4		7.5		1460		380		15.2		92.6		0.81		49.6		2.0		7.5	2.3	71
YE4-160M-4		11		1470		380		21.5		93.3		0.83		71.5		2.2		7.7	2.3	73
YE4-160L-4		15		1470		380		28.8		93.9		0.84		97.4		2.2		7.8	2.3	73
YE4-180M-4		18.5		1475		380		35.1		94.2		0.85		120		2.0		7.8	2.3	76
YE4-180L-4		22		1475		380		41.5		94.5		0.85		142		2.0		7.8	2.3	76
YE4-200L-4		30		1475		380		56.4		94.9		0.85		194		2.0		7.3	2.3	76
YE4-225S-4		37		1480		380		69.4		95.2		0.85		239		2.0		7.4	2.3	78
YE4-225M-4		45		1480		380		84.1		95.4		0.85		290		2.0		7.4	2.3	78

YE4-250M-4		55		1480		380		101		95.7		0.86		355		2.0		7.4	2.3	79
YE4-280S-4		75		1485		380		136		96.0		0.87		484		2.0		6.9	2.3	80

YE4-280M-4		90		1485		380		162		96.1		0.88		579		2.0		6.9	2.3	80

YE4-315S-4		110		1490		380		195		96.3		0.89		707		2.0		7.0	2.2	88

YE4-315M-4		132		1490		380		234		96.4		0.89		849		2.0		7.0	2.2	88

YE4-315L1-4		160		1490		380		280		96.6		0.90		1029		2.0		7.1	2.2	88

YE4-315L2-4		185		1490		380		323		96.7		0.90		1190		2.0		7.1	2.2	88

YE4-315L3-4		200		1490		380		349		96.7		0.90		1286		2.0		7.1	2.2	88

YE4-355M-4		250		1495		380		436		96.7		0.90		1597		2.0		7.1	2.2	95

YE4-355L-4		315		1495		380		549		96.7		0.90		2022		2.0		7.1	2.2	95

YE4-3551-4		355		1495		380		619		96.7		0.90		2275		1.7		7.1	2.2	102
YE4-3552-4		375		1495		380		669		96.7		0.88		2395		1.7		7.1	2.2	102

Type No.	Rated output		Speed		Votage		IN		EFF		Power factor		Rated torque (Tn)		Locked torque		Lockod current Rated torque 1ST/TFL		Max torque Rated toroue TMTFL	Noise level LW dB(A)
YE4	(kW)		( r/min)		(V)		(A)		η(%)		(cosφ)		N.m		Rated torque TST/TFL
380V 50Hz Synchronous Speed 750r/min(8poles)
YE4-80M1-8		0.18		695		380		0.67		67.2		0.61		2.62		1.8		3.3	1.9	52
YE4-80M2-8		0.25		695		380		0.88		70.8		0.61		3.43		1.8		3.3	1.9	52
YE4-90S-8		0.37		700		380		1.24		74.3		0.61		5.05		1.8		4.0	1.9	56
YE4-90L-8		0.55		700		380		1.78		77.0		0.61		7.50		1.8		4.0	2.0	56
YE4-100L1-8		0.75		710		380		2.20		78.4		0.66		10.1		1.8		4.0	2.0	59
YE4-100L2-8		1.1		710		380		3.09		80.8		0.67		14.8		1.8		5.0	2.0	59
YE4-112M-8		1.5		710		380		4.00		82.6		0.69		20.2		1.8		5.0	2.0	61

YE4-132S-8		2.2		720		380		5.65		84.5		0.70		29.2		1.8		6.0	2.0	64
YE4-132M-8		3		720		380		7.58		85.9		0.70		43.3		1.8		6.0	2.0	64
YE4-160M1-8		4		730		380		9.83		87.1		0.71		52.3		1.9		6.0	2.0	68
YE4-160M2-8		5.5		730		380		13.1		88.3		0.72		71.9		1.9		6.0	2.0	68
YE4-160L-8		7.5		730		380		17.2		89.3		0.74		98.1		1.9		6.0	2.0	68
YE4-180L-8		11		735		380		24.9		90.4		0.74		143		2.0		6.5	2.0	70
YE4-200L-8		15		735		380		33.3		91.2		0.75		195		2.0		6.6	2.0	73
YE4-225S-8		18.5		740		380		40.8		91.7		0.75		238		1.9		6.6	2.0	73
YE4-225M-8		22		740		380		47.8		92.1		0.76		284		1.9		6.6	2.0	73
YE4-250M-8		30		740		380		63.8		92.7		0.77		387		1.9		6.5	2.0	75
YE4-280S-8		37		740		380		77.4		93.1		0.78		477		1.9		6.6	2.0	76
YE4-280M-8		45		740		380		93.8		93.4		0.78		580		1.9		6.6	2.0	76

YE4-315S-8		55		745		380		112		93.7		0.80		705		1.8		6.6	2.0	82
YE4-315M-8		75		745		380		151		94.2		0.80		961		1.8		6.2	2.0	82

YE4-315L1-8		90		745		380		179		94.4		0.81		1154		1.8		6.4	2.0	82
YE4-315L2-8		110		745		380		218		94.7		0.81		1410		1.8		6.4	2.0	82
YE4-355M1-8		132		745		380		261		94.9		0.81		1692		1.8		6.4	2.0	90
YE4-355M2-8		160		745		380		312		95.1		0.82		2051		1.8		6.4	2.0	90
YE4-355L-8		200		745		380		388		95.4		0.82		2563		1.8		6.4	2.0	90
Synhronous spoed 600t/min
YE4-315S-10		45		590		380		100.8		91.2		0.75		728.4		1.5		6.2	2.0	82
YE4-315M-10		55		590		380		122.6		91.8		0.75		890.3		1.5		6.2	2.0	82
YE4-315L1-10		75		590		380		163.9		92.3		0.76		1214.0		1.5		5.8	2.0	82
YE4-315L2-10		90		590		380		192.8		92.8		0.77		1456.8		1.5		5.9	2.0	82
YE4-355S-10		(90)		593		380		192.8		92.8		0.77		1449.4		1.5		5.9	2.0	90
YE4-355M1-10		110		593		380		232.1		93.0		0.78		1771.5		1.3		6.0	2.0	90
YE4-355M2-10		132		593		380		277.4		93.3		0.78		2125.8		1.3		6.0	2.0	90
YE4-355L1-10		160		593		380		336.2		93.3		0.78		2979.3		1.3		6.0	2.0	90
YE4-355L2-10		(185)		593		380		388.7		93.3		0.78		2979.3		1.3		6.0	2.0	90

Model	Grade	AC	AD	AG	D	DH	E	EB	ED	F	G	GA	HD	KK		LA	LB	LD	LL	M	N	P	S	T
63M	24	120	120	92	11	M4X12	23	13	5	4	8.5	13	190	1-M25X1.5	225	11	202	90	92	115	95	140	10	3
71M	2,4,6	136	124	92	14	M5X13	30	20	5	5	11	16.5	204	1-M25X1.5	250	11	220	102	92	130	110	160	10	3
80M	2,4,6,8	167	154.5	102	19	M6X16	40	30	5	6	15.5	21.5	254.5	1-M25X1.5	304	12	264	112	102	165	130	200	12	3.5
90S	2,4,6,8	182.4	162	102	24	M8X19	50	40	5	8	20	27	262	1-M25X1.5	336	12	286	130	102	165	130	200	12	3.5
90L	2,4,6,8	182.4	162	102	24	M8X19	50	40	5	8	20	27	262	1-M25X1.5	361	12	311	130	102	165	130	200	12	3.5

100L	2,4,6,8	205.4	173.5	102	28	M8X22	60	50	5	8	24	31	298.5	1-M32X1.5	406	13	346	139	102	215	180	250	14.5	4
112M	2,4,6,8	219.4	190	118	28	M8X22	60	50	5	8	24	31	315	2---M32X1.5	452	14	392	147	110	215	180	250	14.5	4
132S	2,4,6,8	258.4	203	118	38	M12X28	80	65	7.5	10	33	41	353	2-M32X1.5	470	14	390	172	110	265	230	300	14.5	4
132M	4,6,8	258.4	203	118	38	M12X28	80	65	7.5	10	33	41	353	2--M32X1.5	508	14	428	172	110	265	230	300	14.5	4
160M	2,4,6,8	314	251	162	42	M16X36	110	90	10	12	37	45	426	2-M40X1.5	608	15	498	256	152	300	250	350	18.5	5
160L	2,4,6,8	314	251	162	42	M16X36	110	90	10	12	37	45	426	2-M40X1.5	652	15	524	256	152	300	250	350	18.5	5
180M	2,4,8	355	267	162	48	M16X36	110	90	10	14	42.5	51.5	444.5	2-M40X1.5	688	15	578	271	152	300	250	350	18.5	5
180L	4,6,8	355	267	162	48	M16X36	110	90	10	14	42.5	51.5	444.5	2-M40X1.5	726	15	616	271	152	300	250	350	18.5	5

200L	2,4,6,8	397	299	210	55	M20X42	110	100	5	16	49	59	499	2-M50X1.5	779	17	669	296	190	350	300	400	18.5	5
225S	48	446	322	210	60	M20X42	140	125	7.5	18	53	64	547	2-M50X1.5	824	20	684	329	190	400	350	450	18.5	5
225M	2	446	322	210	55	M20X42	110	100	5	16	49	59	547	2-M50X1.5	819	20	709	299	190	400	350	450	18.5	5
225M	4,6,8	446	322	210	60	M20X42	140	125	7.5	18	53	64	547	2-M50X1.5	849	20	709	329	190	400	350	450	18.5	5
250M	2	485	358	248	60	M20X42	140	125	7.5	18	53	64	633	2-M63X1.5	910	22	770	347	218	500	450	550	18.5	5
250M	4,6,8	485	358	248	65	M20X42	140	125	7.5	18	58	69	633	2-M63X1.5	910	22	7700	347	218	500	450	550	18.5	5
280S	2	547	387	248	65	M20X⁴2	140	125	7.5	18	58	69	662	2-M63X1.5	982	22	842	355.5	218	500	450	550	8.5	5
280S	4,6,8	547	387	248	75	M20X42	140	125	7.5	20	67.5	79.5	662	2-M63X1.5	982	22	842	355.5	218	500	450	550	18.5	5
280M	2	647	387	248	65	M20X42	140	125	7.5	18	58	69	662	2-M63X1.5	1033	22	893	355.5	218	500	450	550	18.5	5

280M	4,6,8	547	387	248	75	M20X42	140	125	7.5	20	67.5	79.5	662	2-M63X1.5	1033	22	893	355.5	218	500	450	550	18.5	5
315S	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1194	22	1054	397	280	600	550	660	24	6
315S	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1224	22	1054	427	280	600	550	660	24	6
315M	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1304	22	1164	397	280	600	550	660	24	6
315M	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1334	22	1164	427	280	600	550	660	24	6
315L	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1304	22	1164	397	280	600	550	660	24	6
315L	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1334	22	1164	427	280	600	550	660	24	6
355M	2	698	642	380	75	M20X50	140	130	5	20	67.5	79.5	1042	2-M63X1.5	1486	25	1346	414	330	740	680	800	24	6
355M	4,6,8,10	698	642	380	95	M24X50	170	160	5	25	86	100	1042	2-M63X1.5	1516	25	1346	444	330	740	680	800	24	6
355L	2	698	642	380	75	M20X50	140	130	5	20	67.5	79.5	1042	2-M63X1.5	1486	25	1346	414	330	740	680	800	24	6
355L	4,6,8,10	698	642	380	95	M24X50	170	160	5	25	86	100	1042	2-M63X1.5	1516	25	1346	444	330	740	680	800	24	6

Model	Grade	AC	AD	AG	D	DH	E	EB	ED	F	G	GA	HD	KK	L	LA	LB	LD	LL	M	N	P	S	T
63M	24	120	120	92	11	M4X12	23	13	5	4	8.5	13	190	1-M25X1.5	275	11	202	90	92	115	95	140	10	3
71M	2,4,6	136	124	92	14	M5X13	30	20	5	5	11	16.5	204	1-M25X1.5	300	11	220	102	92	130	110	160	10	3
80M	2,4,6,8	167	154.5	102	19	M6X16	40	30	5	6	15.5	21.5	254.5	1-M25X1.5	354	12	264	112	102	165	130	200	12	3.5
90S	2,4,6,8	182.4	162	102	24	M8X19	50	40	5	8	20	27	262	1-M25X1.5	386	12	286	130	102	165	130	200	12	3.5
90L	2,4,6,8	182.4	162	102	24	M8X19	50	40	5	8	20	27	262	1-M25X1.5	411	12	311	130	102	165	130	200	12	3.5
100L	2,4,6,8	205.4	173.5	102	28	M8X22	60	50	5	8	24	31	298.5	1-M32X1.5	456	13	346	139	102	215	180	250	14.5	4
112M	2,4,6,8	219.4	190	118	28	M8X22	60	50	5	8	24	31	315	2-M32X1.5	502	14	392	147	110	215	180	250	14.5	4
132S	2,4,6,8	258.4	203	118	38	M12X28	80	65	7.5	10	33	41	353	2-M32X1.5	520	14	390	172	110	265	230	300	14.5	4
132M	4,6,8	258.4	203	118	38	M12X28	80	65	7.5	10	33	41	353	2-M32X1.5	558	14	428	172	110	265	230	300	14.5	4
160M	2,4,6,8	314	251	162	42	M16X36	110	90	10	12	37	45	426	2-M40X1.5	668	15	498	256	152	300	250	350	18.5	5
160L	2,4,6,8	314	251	162	42	M16X36	110	90	10	12	37	45	426	2-M40X1.5	712	15	524	256	152	300	250	350	8.5	5
180M	2,4,8	355	267	162	48	M16X36	110	90	10	14	42.5	51.5	444.5	2-M40X1.5	648	15	578	271	152	300	250	350	18.5	5
180L	4,6,8	355	267	162	48	M16X36	110	90	10	14	42.5	51.5	444.5	2-M40X1.5	786	15	616	271	152	300	250	350	18.5	5
200L	2,4,6,8	397	299	210	65	M20X42	110	100	5	16	49	59	499	2-M50X1.5	839	17	669	296	190	350	300	400	18.5	5
225S	48	446	322	210	60	M20X42	140	125	7.5	18	53	64	547	2-M50X1.5	884	20	684	329	190	400	350	450	18.5	5
225M	2	446	322	210	55	M20X42	110	100	5	16	49	59	547	2-M50X1.5	899	20	709	299	190	400	350	450	18.5	5
225M	4,6,8	446	322	210	60	M20X42	140	125	7.5	18	53	64	547	2-M50X1.5	919	20	709	329	190	400	350	450	18.5	5
250M	2	485	358	248	60	M20X42	140	125	7.5	18	53	64	633	2-M63X1.5	970	22	770	347	218	500	450	550	18.5	5
250M	4,6,8	485	358	248	65	M20X42	140	125	7.5	18	58	69	633	2-M63X1.5	970	22	7700	347	218	500	450	550	18.5	5
280S	2	547	387	248	65	M20X42	140	125	7.5	18	58	69	662	2-M63X1.5	1042	22	842	355.5	218	500	450	550	18.5	5
280S	4,6,8	547	387	248	75	M20X42	140	125	7.5	20	67.5	79.5	662	2-M63X1.5	1042	22	842	355.5	218	500	450	550	18.5	5
280M	2	547	387	248	65	M20X42	140	125	7.5	18	58	69	662	2-M63X1.5	1093	22	893	355.5	218	500	450	550	18.5	5
280M	4,6,8	547	387	248	75	M20X42	140	125	7.5	20	675	79.5	662	2-M63X1.5	1093	22	893	355.5	218	500	450	550	18.5	5
315S	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1254	22	1054	397	280	600	550	660	24	6
315S	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1284	22	1054	427	280	600	550	660	24	6
315M	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1364	22	1164	397	280	600	550	660	24	6
315M	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1394	22	1164	427	280	600	550	660	24	6

315L	2	620	527	320	65	M20X42	140	125	7.5	18	58	69	857	2-M63X1.5	1394	22	1164	397	280	600	550	660	24	6
315L	4,6,8,10	620	527	320	80	M20X42	170	160	5	22	71	85	857	2-M63X1.5	1394	22	1164	427	280	600	550	660	24	6

355M	2	698	642	380	75	M20X50	140	130	5	20	67.5	79.5	1042	2-M63X1.5	1546	25	1346	414	330	740	680	800	24	6
355M	4,6,8,10	698	642	380	95	M24X50	170	160	5	25	86	100	1042	2-M63X1.5	1576	25	1346	444	330	740	680	800	24	6

355L	2	698	642	380	75	M20X50	140	130	5	20	67.5	79.5	1042	2-M63X1.5	1546	25	1346	414	330	740	680	800	24	6
355L	4,6,8,10	698	642	380	95	M24X50	170	160	5	25	86	100	1042	2-M63X1.5	1576	25	1346	444	330	740	680	800	24	6

Model	Grade	A	AA	AB	AC	AD	AG	B	BB	C	D	DH	E	EB	ED	F	G	GA	H	HA	K	KK	L	LA	LB	LD	LL	M	N	P	S	T
63M	2.4	100 112	30	130 144	115 135	120 124	92	80	115	40	11	M4X12	23	13	5	4 5	8.5 11	13 16.5	63 71	8 8	4-φ7	1-M25X1.5	225	11	202	90	92	115	95	140	10	3
71M	2,4,6	100 112	32	130 144	115 135	120 124	92	90	120	45	14	M5X13	30	20	5	4 5	8.5 11	13 16.5	63 71	8 8	4-φ7	1-M25X1.5	250	11	220	102	92	130	110	160	10	3
80M	2,4,6,8	125	34	160	167	147	102	100	150	50	19	M6X16	40	30	5	6	15.5	21.5	80	10	4-φ10	1-M25X1.5	304	12	264	112	102	165	130	200	12	3.5
90S	2.4,6,8	140	36	176	182.4	154.5	102	100	161	56	24	M8X19	50	40	5	8	20	27	90	12	4-φ10	1-M25X1.5	336	12	286	130	102	165	130	200	12	3.5
90L	2,4,6,8	140	36	176	182.4	154.5	102	125	186	56	24	M8X19	50	40	5	8	20	27	90	12	4-φ10	1-M25X1.5	361	12	311	130	102	165	130	200	12	3.5
100L	2,4,6,8	160	40	200	205.4	166	102	140	213	63	28	M8X22	60	50	5	8	24	31	100	14	4-φ12	1-M32X1.5	406	13	346	139	02	215	180	250	14.5	4
112M	2,4,6,8	190	50	240	219.4	182	118	140	225	70	28	M8X22	60	50	5	8	24	31	112	15	4-φ12	2-M32X1.	452	14	392	147	110	215	180	250	14.5	4
132S	2,4,6,8	216	55	262	258.4	203	118	140	200	89	38	M12X28	80	65	7.5	10	33	41	132	18	4-φ12	2-M32X1.	470	14	390	172	110	265	230	300	14.5	4
132M	4,6,8	216	55	262	258.4	203	118	178	238	89	38	M12X28	80	65	7.5	10	33	41	132	18	4-φ12	2-M32X1.	508	14	428	172	110	265	230	300	14.5	4
160M	2,4,6,8	254 254	65 65	314	314	251	162	210	260	108	42	M16X36	110	90	10	12	37	45	160	20	4-φ14.5	2-M40X1.	608	15	498	256	52	300	250	350	18.5	5
160L	2,4,6,8	254 254	65 65	314	314	251	162	254	304	108	42	M16X36	110	90	10	12	37	45	160	20	4-1φ4.5	2-M40X1.	652	15	542	256	152	300	250	350	18.5	5
180M	2,4,8	279	70	349	355	267	162	241	311	121	48	M16X36	110	990	10	14	42.5	51.5	180	22	4-φ14.5	2-M40X1.	688	15	578	271	152	300	250	350	18.5	5
180L	4,6,8	279	70	349	355	267	162	279	349	121	48	M16X36	110	90	10	14	42.5	51.5	180	22	4-φ14.5	2-M40X1.	726	15	616	271	152	300	250	350	18.5	5
200L 225S	2,4,6,8	318	70	388	397	299	210	305	369	133	55	M20X42	110	100	5	16	49	59	200	25	4-φ16.5	2-M50X1.	779	17	669	296	90	350	300	400	18.5	5
200L 225S	48	356	75	431	446	322	210	286	368	149	60	M20X42	140	125	7.5	18	53	64	225	28	4-φ18.5	2-M50X1.	824	20	684	329	190	400	350	450	18.5	5
225M	2	356	75	431	446	322	210	31	393	149	55	M20X42	110	100	5	16	49	59	225	28	4-φ18.5	2-M50X1.	819	20	709	299	190	400	350	450	18.5	5
225M	4,6,8	356	75	431	446	322	210	311	393	149	60	M20X42	140	125	7.5	18	53	64	225	28	4-φ18.5	2-M50X1.	849	20	709	329	190	400	350	450	18.5	5
250M	2	406	80	484	485	358	248	349	445	168	60	M20X42	140	125	7.5	18	53	64	250	30	4-φ24	2-M63X1.	910	22	770	347	218	500	450	550	18.5	5
250M	4,6,8	406	80	484	485	358	248	349	445	168	65	M20X42	140	125	7.5	18	58	69	250	30	4-φ24	2-M63X1.	910	22	770	347	218	500	450	550	18.5	5
280S	2	457	85	542	547	387	248	368	485	190	65	M20X42	140	125	7.5	18	58	69	280	35	4-φ24	2-M63X1.	982	22	842	355.5	218	500	450	550	18.5	5
280S	4,6,8	457	85	542	547	387	248	368	485	190	75	M20X42	140	125	7.5	20	67.5	79.5	280	35	4-φ24	2-M63X1.	982	22	842	355.5	218	500	450	550	18.5	5
280M	2	457	85	542	547	387	248	419	536	190	65	M20X42	140	125	7.5	18	58	69	280	35	4-φ24	2-M63X1.	033	22	893	355.5	218	500	450	550	18.5	5
280M	4,6,8	457	85	542	547	387	248	419	536	190	75	M20X42	140	125	7.5	20	67.5	79.5	280	35	4-φ24	2-M63X1.	033 1194	22 22	893	355.5000	218	500 600	450	550	18.5	5
315S	2	508	120	628	620	527	320	406	570	216	65	M20X42	140	125	7.5	18	58	69	315	45	4-φ28	2-M63X1.5	033 1194	22 22	054	397.0000	280	500 600	550	660	24	6
3158	4,6,8,10	508	120	628	620	527	320	406	570	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1224	22	1054	427	280	600	550	660	24	6
315M	2	508	120	628	620	527	320	457	680	216	65	M20X42	140	125	7.5	18	58	69	315	45	4-φ28	2-M63X1.5	1304	22	1164	397	280	600	550	660	24	6
315M	4,6,8,10	508	120	628	620	527	320	457	680	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1334	22	164	427	280	600	550	660	24	6
315L	2	508	120	628	620	527	320	508	680	216	65	M20X42	140	125	7.5	18	58	69	315	45	4-φ28	2-M63X1.5	1304	22	1164	397	280	600	550	660	24	6
315L	4,6,8,10	508	120	628	620	527	320	508	680	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1334	22	1164	427	280	600	550	660	24	6
355M	2	610	116	726	698	642	380	560	750	254	75	M20X50	140	130	5	20	67.5	79.5	355	52	6-φ28	2-M63X1.5	1486	25	1346	414	330	740	680	800	24	6
355M	4,6,8,10	610	116	726	698	642	380	560	750	254	95	M24X50	170	160	5	25	86	100	355	52	6-φ28	2-M63X1.5	1516	25	1346	444	330	740	680	800	24	6
355L	2	610	116	726	698	642	380	630	750	254	75	M20X50	140	130	5	20	67.5	79.5	355	52	8-φ28	2-M63X1.5	1486	25	1346	414	330	740	680	800	24	6
355L	4.,6,8,10	610	116	726	698	642	380	630	750	254	95	M24X50	170	60	5	25	86	100	355	52	6-φ28	2-M63X1.5	1516	25	1346	444	330	740	680	800	24	6

Model	Grade	A	AA	AB	AC	AD	AG	B	BB	C	D	DH	E	EB	ED	F	G	GA		HA	K	KK	L	LD	LL
63M	24	100	30	130	115	120	92	80	115	40	11	M5X12	23	13	5	4	8.5	13	63	8	4-Φ7	1-M25X1.5	225	90	92
71M	2,4,6	112	32	144	135	124	92	90	120	45	14	M5X12	30	20	5	5	11	16.5	71	71	4-Φ7	1-M25X1.5	250	102	92
80M	2,4,6,8	125	34	160	167	147	102	100	150	50	19	M6X16	40	30	5	6	15.5	21.5	80	10	4-φ10	1-M25X1.5	304	119	402
90S	2,4,6,8	140	36	176	182.4	154.5	102	100	161	56	24	MBX19	50	40	5	8	20	27	90	12	4-010	1-M25X1.5	336	143	102
90L	2,4,6,8	1403	36	176	182.4	154.5	102	125	186	56	24	M8X19	50	40	5	8	20	27	90	12	4-Φ10	1-M25X1.5	361	143	102
100L	2,4,6,8	160	40	200	205.4	166	102	140	213	63	28	M8X22	60	50	5	8	24	31	100	14	4-φ12	1-M32X1.5	406	147	102
112M	2,4,6,8	190	50	240	219.4	182	118	140	225	70	28	M8X22	60	50	5	8	24	31	112	15	4-φ12	2-M32X1.5	452	147	110
132S	2,4,6,8	216	55	262	258.4	203	118	140	200	89	38	M12X28	80	65	7.5	10	33	41	132	18	4-Φ12	2-M32X1.5	470	172	110
132M	4,6,8	216	55	262	258.4	203	118	178	238	89	38	M12X28	80	65	7.5	10	33	41	132	18	4-φ12	M-M32X1.5	508	172	110
160M	2,4,6,8	254	65	314	314	251	162	210	260	108	42	M16X36	110	90	10	12	37	45	160	20	4-φ14.5	2-M40X1.5	608	256	152
160L	2.4,6,8	254	65	314	314	251	162	254	304	108	42	M16X36	110	90	10	12	37	45	160	20	4-φ14.5	2-M40X1.5	652	256	152
180M	2,4,8	279	70	349	355	267	162	241	311	121	48	M16X36	110	90	10	14	42.5	51.5	180	22	4-φ14.5	2-M40X1.5	688	271	152
180L	4,6,8	279	70	349	355	267	162	279	349	121	48	M16X36	110	90	10	14	42.5	51.5	180	22	4-φ14.5	2-M40X1.5	726	271	152
200L	2,4,6,8	7 318	70	388	397	299	210	305	369	133	55	M20X42	110	100	5	16	49	59	200	25	4-φ16.5	2-M50X1.5	779	296	190
225S	48	356	75	431	446	322	210	286	368	149	60	M20X42	140	125	7.5	18	53	64	225	28	4-φ18.5	2-M50X1.5	824	329	190

225M	2	356	75	431	446	322	210	311	393	149	55	M20X42	110	100	5	16	49	59	225	28	4-φ18.5	2-M50X1.5	819	299	190
225M	4,6,8	356	75	431	446	322	210	311	393	149	60	M20X42	140	125	7.5	18	53	64	225	28	4-φ18.5	2-M50X1.5	849	329	190
250M	2	406	80	484	485	358	248	349	445	168	60	M20X42	140	125	7.5	18	53	64	250	30	4-φ24	2-M63X1.5	910	347	218
250M	4,6,8	406	80	484	485	358	248	349	445	168	65	M20X42	140	125	7.5	18	58	69	250	30	4-Φ24	2-M63X1.5	910	347	218
280S	2	457	85	542	547	387	248	368	485	190	75	M20X42	140	125	7.5	18	58	69	280	35	4-Φ24	2-M63X1.5	982	355.5	218
280S	4,6,8	457	85	542	547	387	248	368	485	190	65	M20X42	140	125	7.5	20	67.5	79.5	280	35	4-Φ24	2-M63X1.5	982	355.5	218
280M	2	457	85	542	547	387	248	419	536	190	65	M20X42	140	125	7.5	18	58	69	280	35	4-φ24	2-M63X1.5	1033	355.5	218
280M	4,6,8	457	85	542	547	387	248	419	536	190	75	M20X42	140	125	7.5	20	67.5	79.5	280	35	4-Φ24	2-M63X1.5	1033	355.5	218
315S	2	508	120	628	620	527	320	406	570	216	65	M20X42	140	125	7.4	18	58	69	315	45	4-φ28	2-M63X1.5	1194	397	280
315S	4,6,8,10	508	120	628	620	527	320	406	570	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1224	427	280
315M	2	508	120	628	620	527	320	457	680	216	65	M20X42	140	125	7.5	18	58	69	315	45	4-φ28	2-M63X1.5	1304	397	280
315M	4,6,8,10	508	120	628	620	527	320	457	680	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1334	427	280
315L	2	508	120	628	620	527	320	508	680	216	65	M20X42	140	125	7.5	18	58	69	315	45	4-φ28	2-M63X1.5	1304	397	280
315L	4,6,8,10	508	120	628	620	527	320	508	680	216	80	M20X42	170	160	5	22	71	85	315	45	4-φ28	2-M63X1.5	1334	427	280
355M	2	610	116	726	698	642	380	560	750	254	75	M20X50	140	130	5	20	67.5	79.5	355	52	6-φ28	2-M63X1.5	1486	414	330
355M	4,6,8,10	610	116	726	698	642	380	560	750	254	95	M24X50	170	160	5	25	86	100	355	52	6-φ28	2-M63X1.5	1516	444	330
355L	2	610	116 116	726	698	642 642	380 380	630	750	254	75	M20X50 M24X50	140	130	5	20	67.5	79.5	355 355	52 52	6-φ28 6-φ28	2-M63X1.5 2-M63X1.5	1486 1516	414	330
355L	4,6,8,10	610		726	398			630	750	254	95		170	160	5	25	86	100						444	330

Type No.	Rated output	Speed	Votage	IN		EFF	Power factor		Rated torque (Tn)	Locked torque	Lockod current Rated torque 1ST/TFL	Max torque Rated toroue TMTFL		Noise level LW dB(A)
YE4	(kW)	( r/min)	(V)	(A)		η(%)	(cosφ)		N.m	Rated torque TST/TFL
380V 50HzSynchronous speed 1000r/min(6pales)
YE4-80M1-6	0.37	930	380	1.06	78.0		0.68	3.82		2.0	4.7	2.1	54
YE4-80M2-6	0.55	930	380	1.48	80.9		0.70	5.68		2.0	4.7	2.1	54
YE4-90S-6	0.75	940	380	2.03	82.7		0.70	7.62		2.0	6.0	2.1	57
YE4-90L-6	1.1	945	380	2.84	84.5		0.70	11.1		2.0	6.0	2.1	57
YE4-100L-6	1.5	950	380	3.72	85.9		0.71	14.9		2.0	6.5	2.1	61
YE4-112M-6	2.2	950	380	5.40	87.4		0.71	22.1		2.0	6.6	2.1	65
YE4-132S-6	3	960	380	7.24	88.6		0.71	29.8		2.0	6.8	2.1	69
YE4-132M1-6	4	960	380	9.41	89.5		0.72	39.8		2.0	6.8	2.1	69
YE4-132M2-6	5.5	965	380	13.0	90.5		0.72	54.4		2.0	7.0	2.1	69
YE4-160M-6	7.5	970	380	16.6	91.3		0.76	73.8		2.0	7.0	2.1	73
YE4-160L-6	11	970	380	23.7	92.3		0.77	108		2.0	7.2	2.1	73
YE4-180L-6	15	975	380	30.8	92.9		0.80	147		2.0	7.3	2.1	73
YE4-200L1-6	18.5	980	380	37.7	93.4		0.80	180		2.0	7.3	2.1	73
YE4-200L2-6	22	980	380	43.9	93.7		0.81	214		2.0	7.4	2.1	73
YE4-225M-6	30	980	380	58.9	94.2		0.82	292		2.0	6.9	2.1	74
YE4-250M-6	37	985	380	71.6	94.5		0.83	361		2.0	7.1	2.1	76
YE4-280S-6	45	985	380	86.8	94.8		0.83	439		2.0	7.3	2.0	78

YE4-280M-6	55	985	380	104	95.1		0.84	536		2.0	7.3	2.0	78
YE4-315S-6	75	990	380	142	95.4		0.84	727		1.6	6.6	2.0	83

YE4-315M-6	90	990	380	169	95.6		0.85	873		1.6	6.7	2.0	83

YE4-315L1-6	110	990	380	206	95.8		0.85	1066		1.6	6.7	2.0	83

YE4-315L2-6	132	990	380	244	96.0		0.86	1280		1.6	6.8	2.0	83

YE4-355M1-6	160	995	380	295	96.2		0.86	1551		1.6	6.8	2.0	85

YE4-355M2-6	185	995	380	340	96.3		0.86	1793		1.6	6.8	2.0	85

YE4-355M3-6	200	995	380	368	96.3		0.86	1939		1.6	6.8	2.0	85

YE4-355L-6	250	995	380	460	96.5		0.86	2424		1.6	6.8	2.0	85

YE4-3551-6	280	995	380	540	96.5		0.82	2687		1.6	6.8	2.0	91
YE4-3552-6	315	995	380	607	96.6		0.82	3054		1.6	6.8	1.8	91

About Us

Zhejiang Shenli Explosion proof Electromechanical Co., Ltd.

Zhejiang Shenli Explosion proof Electromechanical Co., Ltd. is a modern enterprise specializing in the production of explosion-proof axial flow fans, and providing customized IE4 high efficiency asynchronous motor products, centrifugal ventilation fans, and civilian fans. All fans are produced strictly in accordance with the national level 2 energy efficiency standards. Our company regards talent as the foundation of enterprise development and has strong technical strength and abundant human resources. Guided by scientific production management, the production workshop adopts a closed modern factory building with its own experimental center, processing center, testing center and equipment, ensuring strong product quality and winning wide trust and praise from users. To face the market with professional skills, greater investment, and continuous innovation. With a nationwide marketing network and scientific sales philosophy, combined with quality and brand, it has created strong competitiveness, making it stand out among its peers. As a professional IE4 asynchronous motor manufacturer and global supplier Factory, our products are sold well throughout the country and Southeast Asia.

Jun.05.2026
Why Choose an Explosion Proof Air Blower for Safe Industrial Ventilation
Ventilation systems in industrial spaces are often installed in areas where air conditions are not stable or fully controlled...
May.29.2026
What Determines Industrial Centrifugal Air Blower Performance
In practical use, an Industrial Centrifugal Air Blower is rarely judged by one point alone. People usually notice it through ...
May.22.2026
What Should You Know Before Choosing an Industrial Air Exhaust Fan
A workshop can look open and still hold heat, stale air, or drifting dust in places that are hard to notice. That is where an...

Product Categories

Contact Us

YE4 Series High Efficiency Three Phase Asynchronous Motor

Do you have questions? Do not wait, Let's talk!

Quick Links

Products:

Contact Us

Mobile
