Y5-47 Efficient & Low Noise Boiler Centrifugal Induced Draught Fan

Zhejiang Shenli Explosion proof Electromechanical Co., Ltd.
Tel: +86-13586259916
E-mail:[email protected]
+ Get A Quote
High Temperature Centrifugal Fan for Boiler Exhaust
PREV: G4-73 Y4-73 Boiler Centrifugal Ventilation and Induced Draft Fan
NEXT:No next product
Product Advantages Product Features

The Model Y5-47 boiler centrifugal induced-draft fan features low noise levels, a simple structure, and flexible adjustability of both airflow volume and direction. It is suitable for use with industrial boilers that burn various types of coal and are equipped with smoke elimination and dust removal systems. The fan is designed to convey gases with temperatures not exceeding 250°C. This fan is available in two transmission configurations—Type C and Type D—and comes equipped with an integrated water-cooled bearing housing and an airflow control damper. If vibration isolators are selected, users may place the fan directly onto a level concrete surface without the need for anchor bolts, thereby facilitating easy installation and commissioning.

Immediately D1 Import and export size Import and export size
D2 D3 n1-d1 A1 A2 A3 A4 axb cxd n2-d2
3.15  φ315 φ350 Φ370 12-Φ8 199  255  164  215  3×78 3×64 12-Φ7
4  φ400 φ440 φ462 12-Φ11 253  321  206  266  3x79 3x80 12-φ9
5  φ500 φ540 φ572 16-Φ11 317  382  256  317  3x119 3x97 12-09
6  φ600 φ645 Φ676 16-Φ13 380  446  306  367  4×106 3×114 14-Φ12
7  φ700 φ750 Φ785 16-Φ15 403  511  350  418  4x121 3x130 14-Φ12
8  φ800 Φ860 φ910 16-φ15 507  619  400  509  6x95 5x92 22-Φ15
9  φ900 φ960 Φ1010 16-Φ15 570  682  450  559  6x105 5x103 22-Φ15

Immediately Shape and installation dimensions Fan weight
Excluding motor
(kg)
G M L N K F a a1 b T E n3-d3
3.15  477  587  800  360  222  202  574  537  860  660  270  4-Φ15 120
4  610  749  989  460  282  258  634  597  1100  900  350  4-Φ15 170
5  757  921  1100  560  352  615  634  597  1300  1100  449  6-Φ18 240
6  896  1092  1269  660  422  375  730  690  1300  1100  539  6-Φ18 310
7  1041  1259  1277  748  493  435  755  715  1380  1180  522  6-Φ18 455
8  1185  1574  1701  900  562  498  1312  1264  1728  1528  568  6-Φ18 820
9  1330  1760  1791  1010  633  558  1352  1304  1788  1588  638  6-φ18 910

Immedliately Speed
(r/min)		 With motor
(kw-P)		 Traffic
(m3/h)		 Total pressure
(Pa)
3.15C 3250 1.5-2 1323-2496 1049-716
3.15C 2990  1.5-2 1218-2297 883-608
3.15C 2750  1.5-2 1120-2112 745-520
4C 2900  3-2 2417-4561 1481-1079
4C 3300  4-2 2751-5190 1922-1393
5C 2620  5.5-2 4267-8048 1893-1373
5C 2900  7.5-2 4723-8909 2324-1687
6C 2620  15-2 7372-13908 2844-2069
6C 2850 18.5-2 8020-15129 3364-2452
7C 2580 30-2 11529-21747 3756-2746
7C 2200 18.5-4 9830-18545 2736-1991
8C 2020 30-4 13474-25417 3001-2187
8C 1860 22-4 12407-23404 2550-1853
9C 1800 37-4 17095-32247 3020-2197
10D 1480 37-4 19281-31551 2697-2246
12D 1480 75-4 33318-50356 3628-3393
